Description
5MP CMOS Camera
The HD Lite uses a new 5 Megapixel HD image sensor. The detail of the subject is clearly presented, providing excellent image quality.
Perfect Color Reproduction
Tucsen’s HD Lite camera can process colour with a completely new level of precision, resulting in extremely-high color definition, perfectly matching the monitor image to the eyepiece view.
Intelligent Image Processing
The HD Lite automatically analyzes the acquired images and optimizes the white balance, exposure time and saturation to present perfect images. Whether it is used for brightfield bioimaging or darkfield birefringent crystal imaging, the HD Lite delivers incredible images with minimal need for parameter adjustment.
Specification
| Model | HD Lite |
| Sensor Type | CMOS |
| Sensor Model | ON MT9P001I12STC |
| Color/Mono | Color |
| Array Diagonal | 7.13 mm |
| Resolution | 2 MP, 2592 (H) x 1944 (V) |
| Pixel Size | 2.2 μm x 2.2 μm |
| Effective Area | 5.7 mm x 4.3 mm |
| Shutter Mode | Rolling |
| Frame Rate | 15 fps @ USB2.0, 15 fps @ HDMI |
| Exposure Time | 1 ms – 2 s |
| SD Format | FAT32 |
| Color Temperature | 1800-10000 K |
| Software | HDMI:Cloud 1.0 Ver; USB:Mosaic V2 |
| HDMI Key Settings | Preview: 1920 x 1080; Capture: 2592 x 1944; Vedio recording: 15fps@1920×1080 |
| Picture Format | HDMI: JPG/TIF; USB: TIFF/JPG/PNG/DICOM |
| Multiple Cameras | Supports 4 Cameras Simultaneously in SDK |
| Optical Interface | Standard C Mount |
| Power | 2.4 W |
| Dimensions | 90.7 mm x 74 mm x 67.2 mm |
| Weight | 265 g |
| Data Interface | HDMI, USB2.0, SD card |
| Operating Environment | Temperature: -10~45 ℃; Humidity:10%~85% |
| Operating System | Windows 7/10 (32 Bit/64 Bit)/Mac |
| PC Configuration | CPU: Intel Core i5 or better(Quad or more Core); RAM: 8G or more |
