Description
Live Stitching
The MIchrome 5 Pro can generate large-sized mosaic images in a few seconds while moving the stage, which is smooth and easy!
Live EDF
While turning the focus ring to image different depth-of-field points, the MIchrome 5 Pro automatically generates clear, large depth-of-field images quickly, accurately and efficiently.
Global Shutter Technology
With global shutter technology, all pixels are exposed simultaneously, allowing accurate tracking and capture of dynamic samples providing crisp, undistorted, clear images of fast-moving specimens.
Specification
| Model | MIchrome 5 Pro |
| Sensor Type | CMOS |
| Sensor Model | SONY IMX264LQR-C |
| Color/Mono | Color |
| Array Diagonal | 11.1mm |
| Resolution | 5MP, 2448(H) x 2048(V) |
| Pixel Size | 3.45μm x 3.45μm |
| Effective Area | 8.4mm x 7.1mm |
| Shutter Mode | Global |
| Frame Rate | 36fps@USB3.0 |
| Exposure Time | 121μs-15s |
| Binning | 2×2, 3×3, 4×4 |
| Color Temperature | 2000-15000K |
| PC Software | Mosaic V2 |
| Picture Format | TIFF/JPG/PNG/DICOM |
| Multiple Cameras | Supports 4 Cameras Simultaneously in SDK |
| SDK | C/C++, C#, Directshow/Twain |
| Bit Depth | 16/8bit |
| Power | 3W |
| Operating Environment | Temperature: -10~45℃; Humidity:10%~85% |
| Optical Interface | Standard C Mount |
| Data Interface | USB3.0 |
| Dimensions | 68mm x 68mm x 46mm |
| Camera Weight | 327g |
| Operating System | Windows 7/10 (32 Bit/64 Bit)/Mac |
| PC Configuration | CPU: Intel Core i5 or better(Quad or more Core), RAM: 8G or more |
