Additional information
| Central WL | |
|---|---|
| Wavelength | 532±1 nm |
| Operating Mode | Actively |
| Single Pulse Energy | 1-5 mJ |
| Pulse Duration | <10 ns |
| Jitter | <1ns (Int.) (sdev) |
| Repetition Rate | 1-10Hz (adjustable) |
| Energy Stability | <5%, <3% |
| Beam Divergence (mrad) | <3 mrad |
| Beam Diameter At The Aperture (mm,1/e²) | ~2.5 mm (1/e²) |
| Warm-up Time (minutes) | <15 minutes |
| Beam Height From Base Plate (mm) | 37 mm |
| Cooling Method | Conduction cooled |
| Operating Temperature (℃) | 15-30 °C |
| Power Supply (110/220VAC) | Psu-dps-a-i/psu-dps-a-ii/psu-dps-a-oem |
| Expected Life Time (hours) | 109 pulses |
| Available Options | Battery Powered; Attenuator; |
